How to Measure Contact Resistance of Circuit Breaker
Measuring circuit breaker contact resistance is an important maintenance task for low-voltage and medium-voltage switchgear. A high resistance reading can indicate worn contacts, loose connections, oxidation, contamination, or mechanical problems inside the breaker. If these issues are ignored, the connection can develop excessive heat and eventually lead to contact failure.
This guide explains how to measure contact resistance of circuit breaker using a micro-ohmmeter, including the required testing equipment, preparation, test connections, step-by-step procedure, acceptable readings, and common mistakes.
For a broader explanation of test limits, IEC requirements, testing methods, and interpretation of results, see our detailed guide to Circuit Breaker Contact Resistance.
Quick Overview of the Contact Resistance Test
| Test item | Typical requirement |
|---|---|
| Main instrument | Digital micro-ohmmeter |
| Test current | Commonly 50 A to 200 A DC |
| Measurement | Resistance in micro-ohms (µΩ) |
| Breaker condition | Isolated, de-energized, and properly grounded |
| Test position | Breaker closed |
| Test method | Four-wire Kelvin measurement |
| Main purpose | Detect high-resistance current paths |
| Typical test points | Across each breaker pole |
| Key comparison | Phase-to-phase and previous test results |
The exact test current and resistance limits depend on the breaker manufacturer, voltage class, design, contact material, and applicable standard. Manufacturer specifications should always take priority over a generic value.
Table of Contents
Table of Contents
Why Measure Circuit Breaker Contact Resistance?
Circuit breaker contacts carry substantial current when the breaker is closed. Even a small increase in resistance can create additional power loss because heat generation follows the relationship:
P = I²R
As current increases, the effect of contact resistance becomes much more significant. For example, a resistance that appears very small during a low-current measurement can produce considerable heating when the breaker carries hundreds or thousands of amperes.
Contact resistance testing can help identify:
- Pitted or worn main contacts
- Oxidized contact surfaces
- Loose bolted connections
- Poor internal joints
- Damaged contact pressure mechanisms
- Contamination
- Incorrect contact alignment
- Degraded flexible connectors
- Mechanical problems affecting contact pressure
A stable, low reading generally indicates a good conductive path, while a high or inconsistent result deserves further investigation.
Testing Equipment Required
A proper test requires more than a standard digital multimeter. Circuit breaker contact resistance is normally measured in micro-ohms, so a dedicated high-current resistance tester is preferred.
| Equipment | Purpose |
|---|---|
| Micro-ohmmeter | Measures very low resistance accurately |
| Kelvin test leads | Separates current and voltage measurement paths |
| Test clamps | Provides secure connection to breaker terminals |
| Insulated tools | Supports safe mechanical work |
| PPE | Protects personnel during testing |
| Lockout/tagout equipment | Prevents accidental energization |
| Manufacturer test manual | Provides breaker-specific limits |
| Previous test records | Allows trend comparison |
| Cleaning materials | Removes contamination from test points |
A micro-ohmmeter uses a high DC test current to reduce the effect of contact resistance caused by the test leads and connection points.
How a Micro-Ohmmeter Measures Resistance
Most professional micro-ohmmeters use the four-wire Kelvin method. Two leads inject current through the breaker pole, while two separate sensing leads measure the voltage drop.
The instrument then calculates resistance using Ohm’s law:
R = V / I
This arrangement is important because ordinary two-wire resistance measurement includes the resistance of the test leads and their connections.
For example, if the tester applies 100 A and measures a voltage drop of 2 mV:
R = 0.002 V / 100 A = 0.00002 Ω
Therefore:
R = 20 µΩ
This is why a dedicated micro-ohmmeter is much more suitable than a conventional multimeter for this application.
Safety Precautions Before Testing
Before learning how to measure contact resistance of circuit breaker, make sure the breaker is in a safe test condition.
Follow the site’s approved electrical safety procedure and the breaker manufacturer’s instructions.
- De-energize the circuit.
- Isolate the breaker from all possible sources.
- Apply lockout/tagout procedures.
- Verify the absence of voltage using an appropriate voltage-rated tester.
- Discharge stored electrical energy.
- Ground the equipment where required by the test procedure.
- Confirm that the breaker cannot be remotely operated.
- Inspect the test area for damaged equipment or exposed hazards.
- Remove unnecessary personnel from the work area.
Never connect a micro-ohmmeter to an energized circuit.
How to Measure Contact Resistance of Circuit Breaker Step by Step
Step 1: Identify the Breaker and Test Points
Record the breaker manufacturer, model, rating, serial number, and number of poles. Identify the line and load terminals for each pole.
Check the manufacturer’s maintenance manual for the recommended test current and contact resistance limit.
Step 2: Isolate and Verify the Breaker
Make sure the breaker is completely isolated and de-energized. Verify the condition with an appropriate test instrument.
If the breaker is removable, place it in the manufacturer’s recommended maintenance or test position.
Step 3: Inspect the Terminals
Before connecting the tester, inspect the terminals and accessible connections.
Look for:
- Corrosion
- Dirt
- Loose hardware
- Discoloration
- Signs of overheating
- Damaged contact surfaces
Clean connection points according to the manufacturer’s instructions. Do not aggressively remove plating or alter contact surfaces.
Step 4: Close the Breaker
The main contacts must normally be closed during the resistance measurement.
For a drawout breaker, follow the manufacturer’s instructions for placing the breaker in the correct test position before closing it.
Step 5: Connect the Current Leads
Connect the micro-ohmmeter’s current leads to the appropriate line and load terminals of the first breaker pole.
The current leads should make a solid, low-resistance connection.
Step 6: Connect the Voltage Leads
Connect the voltage sensing leads inside the current connections whenever the tester and breaker configuration permit it.
This Kelvin connection allows the instrument to measure the voltage drop across the breaker contacts while minimizing errors from lead resistance.
Step 7: Set the Test Current
Select the test current specified by the breaker manufacturer or approved maintenance procedure.
Many circuit breaker micro-ohm tests use currents such as 50 A, 100 A, or 200 A DC. The correct value is not universal.
Do not automatically select the highest available current. Use the current recommended for the specific breaker.
Step 8: Start the Resistance Test
Start the micro-ohmmeter and allow the test current to stabilize.
The instrument will inject DC current through the breaker pole and measure the resulting voltage drop.
Wait for a stable reading before recording the value.
Step 9: Record the Reading
Record the resistance in micro-ohms for the first pole.
A typical test record should include:
| Test record | Example |
|---|---|
| Breaker | 800 A molded-case breaker |
| Pole | Phase A |
| Test current | 100 A DC |
| Resistance | 28 µΩ |
| Ambient condition | 25°C |
| Test date | Recorded during maintenance |
| Instrument | Micro-ohmmeter |
| Result | Compared with manufacturer limit |
Do not judge a breaker solely from one generic resistance number.
Step 10: Repeat for Every Pole
Repeat the same process for Phase B and Phase C on a three-pole breaker.
For a four-pole breaker, test the neutral pole as specified by the manufacturer.
Compare the results between poles and with previous maintenance records.
Step 11: Reverse or Repeat the Measurement if Required
Some testing procedures call for repeated measurements or current reversal to improve measurement confidence.
Follow the micro-ohmmeter manufacturer’s operating instructions and the breaker manufacturer’s test procedure.
Step 12: Disconnect the Tester Safely
Stop the test current before removing the test leads.
Disconnect the leads carefully, restore the breaker to the required safe position, and complete the site’s restoration and documentation procedure.
How to Interpret Contact Resistance Results
There is no single contact resistance value that applies to every circuit breaker. A reading of 20 µΩ may be normal for one breaker design and unsuitable for another.
The best approach is to compare the measured value with three references:
- Manufacturer’s specified resistance limit
- Previous test results
- Resistance of the other poles under similar conditions
For example:
| Pole | Measured resistance | Comparison |
|---|---|---|
| Phase A | 24 µΩ | Normal trend |
| Phase B | 26 µΩ | Similar |
| Phase C | 25 µΩ | Similar |
This set of readings appears reasonably balanced. However, the final assessment must still follow the manufacturer’s specifications.
A significant increase from previous measurements is often more useful than an isolated reading. Trending allows maintenance teams to identify gradual deterioration before it becomes a serious problem.
For detailed acceptance criteria and testing considerations, refer to our guide on Circuit Breaker Contact Resistance.
What Causes High Contact Resistance?
High readings can have several causes. Common issues include contact wear, oxidation, contamination, insufficient contact pressure, loose connections, and damaged internal components.
| Possible cause | Typical indication |
|---|---|
| Worn contacts | Gradually increasing resistance |
| Oxidation | Higher or unstable readings |
| Loose connection | Local heating or abnormal resistance |
| Contamination | Inconsistent measurements |
| Poor contact pressure | Elevated resistance across one pole |
| Damaged flexible connector | High resistance on affected pole |
| Misalignment | Uneven pole readings |
| Overheating | Discoloration and increased resistance |
Do not immediately replace a breaker because of one unusual measurement. First verify the test connections, instrument setup, test current, and manufacturer limits.
Common Mistakes During the Test
Poor testing practices can produce misleading results.
Using a Standard Multimeter
A standard multimeter is generally unsuitable for accurate circuit breaker contact resistance testing because its test current is too low for this application.
Using a Two-Wire Connection
Two-wire testing can include lead and connection resistance. A four-wire Kelvin setup provides much better accuracy for low-resistance measurements.
Testing an Open Breaker
The main contacts need to be closed for a contact resistance measurement. Testing an open breaker will not provide a meaningful main-contact resistance value.
Ignoring Test Lead Placement
Poor Kelvin lead placement can affect the measured result. Follow the tester manufacturer’s recommended connection arrangement.
Comparing Different Breaker Designs
Resistance values should not be compared blindly between different breaker models. Contact construction and ratings can vary significantly.
Ignoring Previous Results
Maintenance history is valuable. A trend showing resistance increasing over several inspections can reveal deterioration even when the latest result has not exceeded the manufacturer’s limit.
How Often Should Contact Resistance Be Tested?
The testing interval depends on the equipment, operating environment, manufacturer recommendations, maintenance program, and applicable standards.
Testing may be performed during:
- Commissioning
- Preventive maintenance
- Major shutdowns
- Breaker servicing
- Troubleshooting
- Post-fault inspections
- Periodic switchgear maintenance
Industrial facilities with critical loads may use more frequent condition-based testing.
Frequently Asked Questions
1. What instrument is used to measure circuit breaker contact resistance?
A digital micro-ohmmeter, also called a low-resistance ohmmeter or DLRO, is commonly used. It applies a controlled DC test current and measures the voltage drop across the breaker contacts.
2. What test current is used for contact resistance testing?
Common test currents include 50 A, 100 A, and 200 A DC, but the correct current depends on the breaker manufacturer and applicable test procedure. Always follow the equipment documentation.
3. What is a good contact resistance value for a circuit breaker?
There is no universal value. The acceptable limit depends on the breaker design and manufacturer. Compare the result with the manufacturer’s specification and previous test data.
4. Can I measure breaker contact resistance with a multimeter?
A standard multimeter is generally not recommended. Its low test current and two-wire measurement method can produce less useful results. A four-wire micro-ohmmeter is the preferred instrument.
5. Why is contact resistance testing important?
It helps identify deteriorating contacts, loose connections, oxidation, overheating risks, and other problems that can increase electrical losses and reduce breaker reliability.
Final Thoughts
Knowing how to measure contact resistance of circuit breaker is useful for commissioning, troubleshooting, and preventive maintenance. The test itself is straightforward when the correct micro-ohmmeter, Kelvin connections, test current, and safety procedures are used.
The most important point is not to rely on a generic resistance value. Always compare measurements with the breaker manufacturer’s specification, previous test results, and the readings from other poles.
For a complete reference covering measurement methods, acceptable limits, testing procedures, and relevant standards, explore Circuit Breaker Contact Resistance.
A properly documented resistance test can help detect developing problems early and support a more reliable switchgear maintenance program.
