IEC Standard for Cable Tray: Complete Technical Guide

Understanding the IEC Standard for Cable Tray

Cable trays play a vital role in supporting electrical cables and wires in commercial, industrial, and utility installations. For proper installation, design, and maintenance, adherence to international standards is essential. One of the most recognized frameworks globally is the IEC standard for cable tray systems. This standard ensures safety, durability, and performance across various environments.

The International Electrotechnical Commission (IEC) provides detailed guidelines for cable tray systems under IEC 61537. This standard outlines the construction requirements, testing methods, and performance parameters for cable trays and related support systems. Whether you’re designing a new facility or upgrading an existing electrical infrastructure, understanding and applying the IEC standard for cable tray is crucial.

What Is IEC 61537 and Why Does It Matter?

IEC 61537 is the internationally recognized benchmark for metal cable tray systems. It applies to cable trays made of steel, stainless steel, aluminum, or other metallic materials. The standard ensures these systems can handle the physical and electrical loads they’re exposed to over time.

Following this standard helps engineers, electricians, and contractors make informed choices. It also ensures compatibility and safety across projects. Manufacturers are also required to meet IEC 61537 to legally supply trays in most international markets.

Moreover, compliance with IEC standards reduces the chances of electrical hazards, system failures, and costly reworks. It’s not just about regulation—it’s about ensuring long-term efficiency and safety in cable management systems.

Know more about Contact Resistance Test IEC Standard

Key Components Covered Under IEC Standard for Cable Tray

The IEC standard for cable tray includes multiple technical and performance-based criteria. Here’s a deeper look at what it addresses:

1. Mechanical Strength
The cable tray must withstand the load of cables, environmental factors, and external pressure. IEC 61537 specifies load testing methods to validate tray strength.

2. Corrosion Resistance
The trays must have appropriate coatings or materials to resist corrosion, especially in marine, coastal, or chemical environments.

3. Electrical Continuity
Cable trays often serve as a grounding path. The standard requires the trays to ensure electrical continuity when tested.

4. Fire Resistance
The standard provides guidance on how trays perform under high-temperature and fire conditions. This is essential in critical facilities like hospitals and power plants.

5. Ventilation and Fill Ratio
IEC 61537 offers recommendations on tray perforation and fill capacity. Proper ventilation helps with cable cooling and prevents overloading.

6. Installation Compatibility
It ensures that cable trays are compatible with various fittings, bends, risers, and other accessories for a seamless installation.

Know more about IEC Standard for Protection Relays

Types of Cable Trays as per IEC 61537

The IEC standard for cable tray recognizes multiple tray types depending on application and structure. Each type serves a different purpose in electrical installations.

Each tray type comes with design and load parameters as guided by IEC 61537. Tray selection depends on factors like cable type, environment, span length, and fire rating.

Load Testing and Span Specifications

A major focus of the IEC standard for cable tray is mechanical performance. IEC 61537 outlines how trays must be tested for strength. This ensures they can support the weight of cables over a given span without excessive sagging.

The trays are tested for deflection and yield strength at different spans—commonly at 1m, 1.5m, and 2m. The standard provides formulas to calculate the working load and safety margin.

Here’s a simplified overview:

These figures may vary by manufacturer, material, and design. However, manufacturers must provide test certificates per IEC 61537 to ensure compliance.

Know more about IEC 62368 1 Leakage Current

Earthing and Electrical Continuity Requirements

An essential part of the IEC standard for cable tray is the electrical continuity requirement. When cable trays are used as part of an earthing path, they must meet specific resistance limits.

IEC 61537 mandates that trays used for bonding or grounding should have a resistance of less than 0.1 ohms across joints. This ensures that in the event of a fault, the tray can safely carry the current without overheating or failing.

Accessories like earthing clamps, jumpers, and bonding plates must also meet the same standard. If trays are painted or coated, continuity tests should be performed post-installation to verify contact.

Material and Finish Requirements

The environment in which the cable tray will be used plays a major role in material selection. IEC 61537 includes specifications for materials and protective finishes:

All trays must undergo salt spray tests and coating thickness tests to ensure the coatings meet the durability levels required under the IEC standard for cable tray.

Know more about Demand Factor as Per NEC

Environmental and Installation Factors

IEC 61537 considers environmental exposure in defining tray performance. Some of the environmental conditions considered include:

• Humidity
• Salt fog (for coastal areas)
• UV exposure
• Mechanical vibration
• Chemical exposure

The standard advises proper tray selection and mounting technique based on the location—whether indoor, outdoor, or corrosive zones.

Installation practices are also addressed. Trays should be installed with correct support spacing, using compatible accessories. Overloading must be avoided, and all bends or junctions should maintain minimum cable bend radius.

Marking and Documentation

Every cable tray must be marked clearly by the manufacturer. According to the IEC standard for cable tray, the following must be included:

• Manufacturer’s name
• Product reference number
• Load rating
• Date or batch of manufacture
• CE marking (if applicable)

Additionally, all products must be accompanied by technical datasheets, installation manuals, and test certificates. These documents must be retained for compliance audits and future maintenance.

Know more about Article 220

Common Related Standards and Codes

While IEC 61537 is the main standard, several related codes and guidelines support its application:

• IEC 60364 – Electrical installations of buildings
• IEC 60695 – Fire hazard testing
• IEC 60068 – Environmental testing
• NEMA VE 1 (North American Equivalent for cable trays)
• ISO 9227 – Salt spray testing

Understanding the interaction between these standards helps engineers make more comprehensive design decisions.

Conclusion: Why Follow the IEC Standard for Cable Tray?

Following the IEC standard for cable tray is not just about regulatory compliance—it’s about ensuring a safe, efficient, and future-proof electrical system. This international standard provides clear, tested, and reliable benchmarks for everything from tray strength to fire resistance and electrical continuity.

For manufacturers, it opens access to global markets. For designers and contractors, it ensures compatibility, reliability, and safety. And for facility owners, it reduces risk and increases the long-term value of infrastructure investments.
